Product info
Made in the USA, the radiometric VUE TZ20-R thermal-zoom drone payload enables DJI V2 Matrice 200 series and 300 pilots to see and measure thermal details not possible with other leading sUAS aircraft and payloads. The TZ20-R features two FLIR Boson® thermal cameras that put four times more pixels on target at every zoom level versus all competition and offers an unmatched 20× zoom capability.
Utility, roofing, solar farm, and other industrial inspectors can zoom into objects of interest, identify them with unmatched clarity, and take and record radiometric temperature measurements, all from a safe standoff distance. Emergency response pilots in search and rescue, law enforcement, firefighting, and public safety can search for and observe in silence while using the thermal zoom to reduce false positives and make critical decisions faster with the affordable VUE TZ20-R.
The combination of performance-leading thermal zoom and radiometry enables more efficient missions with faster search, silent surveillance, and safer stand-off inspections.
Specifications
Aircraft
Airframe capatibility |
DJI V2 Matrice 200-series and Matrice 300
|
Ground control |
DJI Pilot App
|
Electrical
Electrical interface |
Skyport 2.0, 13.6V/2A
|
Enivronmental & approvals
Environmental sealing |
IP44
|
Operational & storage temperature |
Operational: -20° to 45°C (-4° to 113°F) Storage: -20° to 60°C (-4° to 140°F)
|
Tested EMI performance |
FCC part 15 Class B
|
Gimbal
Gimbal range of motion |
3-axis Pitch: 30° to -120° Yaw: ±270°
|
Imaging & optical
IR camera optics |
Wide FOV: 95° HFOV, 4.9 mm EFL Narrow FOV: 18° HFOV, 24 mm EFL
|
IR camera resolution |
2 FLIR Boson 640 × 512
|
Radiometric features |
Spot meter, measurement box with min/max/avg Isotherms above or below threshold temperature
|
Streaming video |
640 × 512 @ 25 Hz
|
Measurement & analysis
Thermal sensitivity |
85 mK @ F/1.0
|
Mechanical
Mechanical interface |
Skyport 2.0 connector, X-Port DJI gimbal
|
Radiometry
Radiometric accuracy |
Accuracy: ±5C / 5% for scenes +10C to +100C Scene dynamic range: -10C to +300C
|
Thermal camera
Video & recording
Recording |
- Still: Radiometric JPEG, raw TIFF Periodic capture 1s – 30s interval, all still image formats Video
- MPEG 25Hz (zoomed)
- Radiometric CSQ 5Hz (zoomed)
- Raw multipage TIFF 10Hz (wide and narrow FOV separate)
|
Features
- Unmatched performance at 5×, 10×, and 20×
- Dual Bosons provide 4× more pixels
- Plug and play with DJI Matrice 300
