Noa is the ultimate multipurpose Remotely Operated Aerial Vehicle for commercial use. Its six enlarged custom Acecore rotors were designed to enable the Pilot in Command to fly for an extended amount of time with various payloads.

Thanks to Noa’s modular quick release, there is no limit to the amount of payload that can be used. Gremsy, Freefly, DJI, and LiDAR all fall within the possibilities. Due to the flexibility in battery options, users can balance payload and battery weight to allow for optimal flight efficiency. The six aerodynamic carbon fibre booms can be removed and redeployed through Acecore’s quick-release system, allowing for improved portability and a toolless setup.

Endurance

The Acecore Noa hexacopter carries A 3kg/ 6.6lbs payload such as the Sony A7R iv and Gremsy T3 V3 gimbal for over 40 minutes. Land surveying, 2D & 3D LiDAR mapping, wind turbine/ powerline inspection and a wide array of professions will find the extended endurance especially useful, covering more ground in a day than ever before.

LiDAR Platform

Noa’s excellent flight performance, endurance, and internally stabilised quick-release make it a workhorse for LiDAR applications. It is capable of laser-guided terrain following and has retractable landing gear for a 360-degree unobstructed field of view. Noa’s generous payload capacity allows users to configure it with the highest spec LiDAR systems reaching accuracies up to 10mm with photo-realistically colored point clouds.

Tool-less Setup

Four battery packs ranging from 11A-23A can be taken from Noa’s carbon fibre flight case and locked into the drone by the new shark fin battery latch. Each of the six booms mount to Noa’s centerpiece using double-action quick-release locks. Screw-on propellor adapters result in a completely toolless setup of the system.

Custom Integrations

Although Acecore offers many of today’s most advanced payloads and setups as off-the-shelf products, we love doing custom projects: it’s what separates us from the rest. Acecore builds commercial/ military spec drones to your wishes so you can stand out in your field of work.

Specifications

Weights

Standard version

Maximum gross take-off weight 36.9 kg
Maximum payload weight 20kg
Minimum standard empty weight 11.4kg

Sub-25kg version

Maximum gross take-off weight 24.9 kg
Maximum payload weight 8.1 kg
Minimum standard empty weight 11.4kg

Dimensions

Frame dimensions 1680x1680x840mm
Rotor-to-rotor diagonal distance 1680mm
Diameter with propellers 2330mm
Height up to the bottom plate 540mm
Ground clearance from the bottom of the propeller 670mm

Drive

Energy type Electrical
Number of motors 6
Motor type Direct Drive 3-phase BLDC out-runner
Operating voltage 42V - 52V
Motor continuous power 2000W
Idle speed 120 RPM/V
Number of ESCs 6
Maximum continuous current draw 40A/motor

Propeller

Material Carbon Fibre Reinforced Plastic ( CFRP) / foamed core 3K Twill weave
Propeller setup 3 CW and 3 CCW propeller
Propeller type 28 x 9.2 inch fixed propeller

Payload

Vibration isolation system Octo metal wire damper system
Mounting options Top and bottom mounting possible
Mounting system Depending on user preference
Battery rack Top of the centrepiece locked by shark fin

Avionics

Flight controller Cube flight controller
Version Orange/ Blue
Operating temperatures -40°C to + 85°C

Flight battery

Energy type Electrical
Battery Lithium Polymer
Recommended make and models 11000mAh, 17000mAh, 23000mAh
Nominal battery voltage 48 V/ 12S
Minimum battery quantity 2 battery packs parallel
Maximum battery voltage 52V
Minimum average battery voltage 42V

Weather limitations

Maximum operating temperature +50°C
Minimum operating temperature -15°C
Maximum flight endurance 60 min
Maximum wind speed 28 knots
Maximum wind gusts 35 knots
Maximum precipitation Moderate rain conditions, although it is recommended to fly in dry conditions.
Maximum downfall 10 mm/h, 30mm/3h

Flight limitations

Maximum pitch/ roll angle 45 Degrees from horizontal
Maximum yaw rate 150 Degrees a second
Maximum flight speed 85 km/h horizontal
Flight modes
  • GPS mode
  • Attitude mode
  • Auto mode
  • Brake mode
  • Stabilise mode
Typical ascent 5m/s
Typical descent 4m/s
Hovering accuracy Vertical 0.05m/ Horizontal 0.05m
RTL cruise speed Variable from 3 m/s to 9 m/s

Features

  • 60-minute flight time
  • 20kg payload
  • 6 motor configuration
  • Dual GNSS GPS
  • ADS-B transponder
  • AES256 encrypted radio link
