Acecore's most optimised UAS ever. The Acecore Zoe has been on the market since 2017, since then it's got an entirely new propulsion system and internal layout bringing the maximum flight time to 47 minutes. Combined with multiband F9P RTK, modular payload bay, and numerous payload integrations, it's the most versatile drone from Acecore to date.

Endless Configurations

Each Zoe is tailor-made to your specifications. Its abundant lifting capacity and modular setup allow users to combine the payload, batteries and additional modules to form the perfectly balanced system for each application - or multiple at once. There is a setup for everything.

  • Security
  • Mapping
  • Inspection
  • LiDAR

4 or 8 Motors

Opt for a quadcopter to get the maximum endurance, or an octocopter to get the most performance and redundancy out of the Zoe platform.

Aerodynamic Design

Zoe’s aerodynamic Dutch-design carbon fibre frame puts it in a class of its own. The way it doesn’t hang but rather stands in the air makes it highly weatherproof. The Acecore Zoe is both wind and rain resistant which means it can operate at continuous wind speeds of 7 Beaufort/ 30 knots with rain up to 9mm/h. The hollow arms generate an active airflow through the entire system and pull hot air out of the motor mounts, away from the critical components. As a result, Zoe will operate at temperatures up to 50 degrees Celsius.

Unlimited Flight Time

Tethering Zoe to an Elistair Safe-T 2 station gives professionals access to unlimited flight times. At 80 metres in height, Zoe can carry a payload of 2.7 kilograms like a Workswell WIRIS Security in a Gremsy S1 gimbal all day. In a tethered operation, Zoe can follow any moving vehicle autonomously- it will keep its position above the van, truck, UGV, boat, or ATV that the Safe-T 2 and high accuracy RTK GPS is mounted to. Leverage this autonomous vehicle follow-me function for new applications such as convoy protection or car LiDAR scanning.

Custom Integrations

Although Acecore offers many of today’s most advanced payloads and setups as off-the-shelf products, we love doing custom projects: it’s what separates us from the rest. Acecore builds commercial/ military spec drones to your wishes so you can stand out in your field of work. Let us know what camera, sensor, module, or other hardware you need to be installed and our engineers will make it happen.

Modular System

Designed with versatility in mind, Zoe’s body is modular and can easily be taken apart for hardware upgrades and customisations. Batteries, landing gear, and entire booms can be interchanged to ensure a future-proof system. The heatsink has several mounting points where additional gear can be secured, and the payload mount is configurable to allow for many third-party payload integrations.

Specifications

Weights

Maximum gross take-off weight 13kg
Maximum payload weight 5.6kg
Minimum standard empty weight 4.2kg

Dimensions

Frame dimensions 693x682x524mm
Rotor-to-rotor diagonal distance 970mm
Diameter with propellers 1310mm
Height up to the bottom plate 320mm
Ground clearance from the bottom of the propeller 388mm

Drive

Energy type Electrical
Number of motors 4
Motor type Direct Drive 3-phase BLDC out-runner
Operating voltage Up to 50V
Motor continuous power 800W
Idle speed 380RPM/V
Number of ESCs 8
Maximum continuous current draw 55A

Propeller

Material Carbon Fibre Reinforced Plastic ( CFRP) / foamed core 3K Twill weave
Propeller setup 2 CW and 2 CCW propeller
Propeller type 21x6. 5-inch fixed propeller

Payload

Vibration isolation system Quad damper system
Mounting options Top and bottom mounting possible
Mounting system Depending on user preference
Battery rack Top of centrepiece or below on quick-release

Avionics

Flight controller Cube/Auterion Skynode
Version Orange
Operating temperatures -40°C to + 85°C

Flight battery

Energy type Electrical
Battery Lithium Polymer
Recommended make and models Tattu 4500mAh, 11000mAh, 17000mAh
Nominal battery voltage 22.2 V/ 6S
Minimum battery quantity 2 battery packs parallel
Maximum battery voltage 25.2V
Minimum average battery voltage 21.0V

Weather limitations

Maximum operating temperature +50°C
Minimum operating temperature -15°C
Maximum flight endurance 47 min
Maximum wind speed 29 knots
Maximum wind gusts 33 knots
Maximum precipitation Moderate rain conditions, although it is recommended to fly in dry conditions.
Maximum downfall 10 mm/h, 30mm/3h

Flight limitations

Maximum pitch/ roll angle 45 Degrees from horizontal
Maximum yaw rate 150 Degrees a second
Maximum flight speed 91km/h horizontal
Flight modes
  • GPS mode
  • Attitude mode
  • Auto mode
  • Brake mode
  • Stabilise mode
Typical ascent 5m/s
Typical descent 4m/s
Hovering accuracy Vertical 0.05m/ Horizontal 0.05m
RTL cruise speed Variable from 3 m/s to 9 m/s

Features

  • 47-minute flight time
  • 5kg maximum payload
  • AES256 encrypted radio link
  • 4 or 8-motor option
  • ADS-B transponder
