Product info
The Sentera Double 4K Sensor is the most versatile sensor for crop performance analytics, capturing aerial imagery that can be turned into orthomosaics and detailed analytics.
Four Variations to Meet Every Use Case
The Double 4K is available in four variations to deliver the imagery required:
- Ag+: RGB + NDVI Multispectral Imagery
- Analytics: Zoom RGB + NDVI Multispectral Imagery
- Multispectral: 5-band Multispectral Mapping
- NDVI/NDRE: NDVI + NDRE
Specifications
| Specification |
Details |
| Sensor |
12.3 MP BSI CMOS RGB
Sony Exmor R IMX377 |
| Lens – Standard |
Focal Length: 5.4 mm
HFOV: 60°
GSD @ 60 m: 1.8 cm
GSD @ 120 m: 3.5 cm |
| Lens – Zoom (Analytics Only) |
Focal Length: 25 mm
HFOV: 14°
GSD @ 60 m: 0.38 cm
GSD @ 120 m: 0.75 cm |
| Dimensions |
59 mm × 40.9 mm × 44.5 mm
(2.32" × 1.61" × 1.75") |
| Weight |
80 g |
| Power Consumption |
8 W typical / 12 W maximum |
| Frame Rate & Capture |
12.3 MP still images
4K Ultra HD video at 30 fps |
| Image & Video Format |
JPEG (stills)
1080p / 720p video
H.264 encoding |
| Storage |
64 GB SD card (standard, removable) |
| Interfaces |
Ethernet
Serial / UART
USB 3.0
I2C
GPIO |
| Configuration |
Web-based camera configuration interface |
| Control & Integration |
Open ICD for triggering and metadata logging over serial or IP
Compatible with PIXHAWK autopilot
MAVLink-based systems supported
Custom ICD options available |
| Compatible Drones |
DJI Mavic 3 Enterprise
DJI Mavic 2 Pro
DJI Phantom 4 Pro |
