Product info
UgCS SkyHub is an onboard computer to log geotagged data from various sensors like GPR, altimeter, magnetometer, and methane detector.
HS Code: 90158020 (meteorological, hydrological, geophysical instrument)
Packaging information: 20х20х10cm, 0.6kg in cardboard box
UgCS SkyHub comes with mountings and cables for the selected type of drone.
Please note that there are no standard mountings for Pixhawk based drones and by default, if you select "Pixhawk" you will get the cable to connect SkyHub to Telem port of autopilot and mountings for M600 Pro drones as they are most universal. Please contact us if you need something different.
Specifications
The UgCS SkyHub 3 device provides a connection to different payloads via several interfaces:
- 3× UART interfaces
- 1× UART / RS-232 interface
- 1× RS-232 interface
- 4× GPIO pin pairs
- Ethernet interface
- Bluetooth interface
- 2× USB 2.0
UgCS SkyHub 3 eliminates the need to have a separate battery or power circuit for the sensors. Every connector with communication ports has pins with +5V and +12V covering 99% of power requirements for the sensors. One additional power connector is configurable and may output 9, 12, 15, 18V with 5A load maximum. Other possibility to power sensors is from a drone power pass-through connector.
General
- Compatible drones
- DJI M210 / M210 V2
- DJI M600 / M600 Pro
- DJI M300 RTK
- Custom frames based on DJI A3 flight controller
- Pixhawk with ArduCopter / PX4
- Temperature range: −25°C to +50°C
- Power input: 12 V to 60 V, UgCS SkyHub itself works from 9+ V
- Power output: selectable 9 V / 12 V / 15 V / 18 V, up to 5 A
Computational core
- System-on-Module: Raspberry Pi Compute Module 4
- CPU: Cortex-A72 (ARM v8) 64-bit
- CPU: frequency up to 1.5 GHz
- RAM: 8 GB
- Flash: eMMC 32 GB
- OS: Ubuntu Server 21.04
Mechanical
- Dimensions: (L × W × H) 112 × 84 × 34 mm
- Weight: 195 g
- Weight with mountings: 215 g for DJI M300, 220 g for DJI M600
Features
- Fully isolated and ESD-protected external interfaces
- Reliable and convenient connectors with lock, ideal for airborne applications
- Selectable power output (9 V / 12 V / 15 V / 18 V) with switch-off function for payload connecting
- Drone power pass-through to external payloads
