Product info
DJI RC Plus 2 Enterprise is equiped with a new high-bright display, ensuring clear visibility even under strong sunlight. The controller has an IP54 protection rating and operates in temperatures from -20°C to 50°C. With the powerful O4 Enterprise video transmission, a built-in high-gain antenna array, and support for both SDR and 4G hybrid transmission, it provides a stable and smooth video feed in both urban and mountainous environments.
Specifications
OcuSync
- Operating Frequency Range* : 5.150-5.250 GHz; 5.725-5.850 GHz
- Transmitter Power (EIRP)
- 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
- 5.1 GHz: <23 dBm (FCC/CE)
- 5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <30 dBm (SRRC)
Wi-Fi
- 802.11 a/b/g/n/ac/ax
- Operating Frequency Range*: 2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz
- Transmitter Power (EIRP)
- 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
- 5.1 GHz: <26 dBm (FCC), <23 dBm (CE/SRRC/MIC)
- 5.8 GHz ＜26 dBm (FCC/SRRC), ＜14 dBm (CE)
Bluetooth
- Bluetooth 5.2
- Working frequency: 2.4000-2.4835 GHz
- Transmitter Power (EIRP): <10 dBm
General
- Model: TKPL2
- Battery Type: Li-ion (6500 mAh @ 7.2 V)
- Chemical System: LiNiCoAlO2
- It is recommended to use USB-C chargers with maximum rated power of 100W
- Rated Power: 12.5 W
- GNSS: GPS + Galileo + BeiDou
- Video Output Port: HDMI Type-A
- Operating Temperature: -4° to 122° F (-20° to 50° C)
- Storage Temperature
- Within one month: -22° to 113° F (-30° to 45° C)
- One to three months: -22° to 95° F (-30° to 35° C)
- Three months to one year: -22° to 86° F (-30° to 30° C)
- Charging Temperature: 41° to 104° F (5° to 40° C)
* Operating frequency allowed varies among countries and regions. Please refer to local laws and regulations for more information.
