U10 UAV Based Laser Methane Leakage Detector

U10 UAV Based Laser Methane Leakage Detector

A$79,999.00
In stock
Out of stock
-
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
+
Add to Cart
Need a hand with this product? Our are team are happy to help - get in touch.
SKU
00001

Product info

The U10 is a light-weight, high-sensitivity gas detector based on Tuneable Diode Laser Absorption Spectroscopy (TDLAS), which enables rapid identification of methane from up to 150 m away, or at a concentration as low as 5ppm.m. Equipped with 3-axis stable gimbal, U10 can automatically resist the interference caused by inevitable vibration. Powered by DJI SkyPort, the U10 can be seamlessly integrated with DJI Matrice 200 Series V1 and V2 platforms, Matrice 300 RTK platforms.

Accurate Results from Afar:

Get real-time readings on the concentration of methane from up to 150 m away, adjust the pitch of the gimbal to pinpoint gas leaks in dangerous or hard-to-reach areas while keeping personnel safe

Visualise the Detection:

The high sensitivity allows detection at a concentration as low as 5ppm.m. Receive concentration data in just 25 ms, so you can make decisions quickly. Gain an aerial overview of the suspected leakage site through the 720p visual camera.

Automated Workflows:

Plan flight missions and view flight paths, monitor gas concentration levels and historical trends in real-time, and flag specific points along the flight route for abnormalities and generate inspection reports – all through the AlphaOne iOS application.

Critical Facility Inspection

Use DJI’s leading drone platforms equipped with the U10 to inspect and maintain facilities like Liquid Natural Gas plants, gas storage tanks, and gas pipelines in areas such that are difficult for human operators to access, such as mountains or rivers. With the U10, users can detect and monitor methane leakages accurately to make informed response decisions quickly.

Specifications

Method of Detection TDLAS Detection target Methane(CH4)
Stationary Detection Limit 5 ppm·m Detection Laser Class IIIR
Response Time 25 ms Operating Temperature -20 ~ 50℃
Sampling Rate 500 KHz Operating Humidity Less than 90%RH, no condensation
Detection Concentration Range 0~50,000 ppm·m Size 174 x 89 x 163 mm
Max Detection Distance 150 m Weight 700g
Camera Video at 720 p Supported Aircraft DJI Matrice 200 Series, Matrice 200 Series V2, Matrice 300 RTK

Features

  • Detects CH4
  • Up to 150m Detection Distance
  • 25 ms Response Time
  • Stationary Detection Limit 5ppm.m
