Product info
The DJI AL1 Spotlight supports two modes: always-on and strobe. It can clearly illuminate subjects even from a distance of 100 metres. Additionally, it can intelligently link with the gimbal, following the camera's movements to ensure the illuminated area matches the camera's view.
It also offers a wide fov lighting mode, which can light up a broader area when in wide-angle mode. The spotlight and speaker can be used independently or in combination, meeting the needs of more operational scenarios.
What's included
- 1x Spotlight
- 1x Spare Screw
- 1x Hex Key
Specifications
- Weight: 99 g (including bracket)
- Approx. 91 g (excluding bracket)
- 95×164×30 mm (L×W×H, including bracket)
- 79×164×28 mm (L×W×H, without bracket)
- Max Power: 32 W
- Illuminance: 4.3±0.2 lux @ 100 metres, 17±0.2 lux @ 50 metres
- Effective Illumination Angle: 23°(10% relative illuminance)
- Effective Illumination Area: 1,300 square metres @ 100 metres (10% relative illuminance, Normal Mode) 2,200 square metres @ 100 metres (10% relative illuminance, Wide fov Mode)
- Modes: Always-on and strobe
- Gimbal Mechanical Range (Tilt): -140° to 50°
- Gimbal Controllable Range (Tilt): -90° to 35°
- Max Control Speed (tilt): 120°/s
- Gimbal Alignment Accuracy: ±0.1°
- Operating Temperature: -20° to 50° C
- Mounting Method: Quick-release hand-tightened screws
