DJI D-RTK 3 Multifunctional Station without DJI Care Enterprise

DJI D-RTK 3 Multifunctional Station without DJI Care Enterprise

A$2,320
A$2,320
In stock
Out of stock
-
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
+
Add to Cart
Need a hand with this product? Our are team are happy to help - get in touch.
Note:
Drone not included.
Note:
Drone not included.
SKU:
00001
Partner:
DJI
Type:
RTK

The new D-RTK 3 Multifunctional Station integrates high-performance antennas and receiver modules, capable of tracking and resolving data from major global satellite navigation systems. It supports multiple data transmission links and can analyse device position and orientation through its built-in high-performance inertial measurement unit.

With these outstanding features, it can serve as a base station to provide centimetre-level positioning for multiple drones simultaneously, or extend the operational range of drones in relay station mode. Additionally, the new rover station mode, combined with the DJI ENTERPRISE app and DJI Terra, offers a one-stop solution for high-precision aerial surveying applications.

Tips when using D-RTK 3 from DJI

  1. Measurement accuracy depends on various factors. This value is obtained under normal conditions with an unobstructed view, good satellite distribution, low ionospheric activity, and no electromagnetic interference or multipath effects.
  2. Intense vibrations and rapid rotations can affect the accuracy of the inertial measurement unit.
  3. The relay station should be placed in a high, unobstructed location to ensure clear communication between the remote controller and the aircraft.
  4. Measured in an unobstructed outdoor environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. Always pay attention to RTH reminders in the app during your flight.
  5. 5. Please make sure all rubber plug interfaces on the body are properly installed.
  • 1x D-RTK 3 Multifunctional Station
  • 4x Spare OcuSync Directional Antennas
  • 1x USB-A to USB-C Cable
  • Diameter: 163 x 89mm (without OcuSync Directional Antennas)
  • Weight: 1.26kg

GNSS Frequency

  • GPS: L1C/A, L2C, L5
  • BDS: B1I, B2I, B3I, B1C, B2a, B2b
  • Galileo: E1, E5a, E5b, E6
  • GLONASS: L1, L2
  • QZSS: L1C/A, L2C, L5
  • L-Band

Rover Station Mode Accuracy

  • Static Measurement
    • Horizontal: 0.8 cm + 1 ppm (RMS)
    • Vertical: 1.5 cm + 1 ppm (RMS)
  • Tilt Measurement
    • Angle Range: 0°to 60°
    • Horizontal: 8 mm + 0.7 mm/° tilt (accuracy <2 cm within 30°)

Max Transmission Distance (in Relay Station Mode, unobstructed, free of interference)

FCC

  • 15km between the aircraft and the relay station
  • 1km between the relay station and the remote controller

SRRC

  • 12km between the aircraft and the relay station
  • 1km between the relay station and the remote controller

CE

  • 8km between the aircraft and the relay station
  • 300m between the relay station and the remote controller
