The Sentera 65R is the first ultra-high-resolution precision sensor built from the ground up for seamless integration with drone systems, including RTK systems.
With a resolution of 9344 x 7000 pixels and a ground sampling distance of 0.45cm/pixel, the 65R Sensor improves efficiency and reduces errors by capturing more pixels per image, meaning you can capture more ground significantly faster than any other camera on the market.
Large sensor size and high-quality lens system capture rich details and accurate colors, ensuring controlled color quality without creative or artistic modes.
Equipped with 65 million pixels of global shutter image capture, integrated pulse-per-second synchronisation, a 58-degree HFOV, and time-of-capture geo-tagging, the 65R ensures high-accuracy data right out of the box.
| Specification | Details |
|---|---|
| Model | 65R |
| Sensor | GPixel GMAX3265 |
| Resolution | 9344 × 7000 |
| Horizontal Field of View (HFOV) | 57.6° × 44.8° |
| Ground Sample Distance (GSD) | 0.45 cm @ 38 m (125 ft) 1.43 cm @ 120 m (200 ft) |
| Focal Length | 27 mm |
| Shutter | Global |
| Pixel Size | 3.2 µm |
| Dimensions (Sensor Only) | 2.5 in × 2.78 in × 4.19 in (63.5 mm × 70.6 mm × 106.4 mm) |
| Weight (Sensor Only) | 330 g |
| Weight (With Gimbal) | Skyport: 580 g Smart Dovetail: 588 g Gremsy Hyper Quick: 564 g |
| Power Consumption | 12 W Typical, 15 W Max |
| Frame Rate | 3 FPS (0.333 s interval) |
| Image Format | 8-bit JPEG (RGB) |
| Storage | 512 GB Internal SSD |
| Interfaces | USB-C Gigabit Ethernet UART Digital I/O |
| Trigger & Sync Features | Input Pulse/PWM for Image Capture Input Pulse Per Second (PPS) for Time/Position Sync Output Pulse for Image Exposure Sync |
| Additional Features | Integrated IMU Pushbutton Trigger Option |
| Compatible Drones | DJI Matrice Series Freefly Astro Inspired Flight IF800 Inspired Flight IF1200 Sentera PHX |
| Compliance | NDAA Compliant Blue UAS Eligible |
| Notes | Specifications are subject to change without notice. Performance figures assume appropriate post-processing. |
