Product info
Extra-lightweight GPR system, suitable for medium-sized drones like DJI M300 RTK.
Comes with 3x sets of dipoles for the 300, 150, and 75Mhz.
Utilizes Real Time Sampling (RTS) with high hardware stacking, delivering high-resolution low-noise data.
HS Code: 90158020 (meteorological, hydrological, geophysical instrument)
What's included
- Zond Aero LF GPR system with 75, 150, 300 MHz centre frequency antennas
- Prism 2 Data Acquisition/Processing software
- NANUK transport case for GPR controller
- Tube for antennas
- Mounting kit to fix GPR system on the DJI M300 RTK or M600/M600 Pro drone
Specifications
| Type |
Single channel Ground Penetrating Radar system with unshielded dipole antenna |
| Center frequency |
75, 150, 300 MHz depending on used antenna |
| Operating bandwidth |
38 – 150, 75 – 300, 150 – 600 MHz (-12 dB) |
| Samples |
256 / 512 / 1024 / 2048 / 4096 / 8192 |
| Sample rate |
up to 1,280,000 samples/second (depends on hardware stacking) |
| Scan rate |
up to 2,500 scans/s (depends on hardware stacking) |
| Sample output |
32 bit digital raw data |
| Time range per sample |
18 ps / 36 ps / 71 ps / 89 ps / 125 ps / 143 ps / 179 ps / 250 ps / 357 ps / 500 ps / 625 ps / 714 ps / 1 ns / 1.25 ns / 2.5 ns |
| Depth |
up to 12 meters in soil with relative dielectric permittivity equal to 5 and specific attenuation up to 5 dB/m. |
| Data format |
Standard Geophysical SEGY Data Format (.sgy) with traces geotagging |
| DOCUMENTATION & DATA SETS |
| Data Sheet |
|
| User Manual |
|
| Data Samples |
|
| ENVIRONMENTAL |
| Temperature |
-20°C to 60°C internal temperature |
| Humidity |
96% non-condensing |
| Ingress protection |
IP68 in a protective box (used for transportation and for ground surveys) IP52 in airborne variant |
| MECHANICAL |
| Weight |
|
| BATTERY |
| Airborne variant |
Drone main battery is used to provide power to the GPR |
