Product info
Sentera's best-in-class 6X multispectral sensor now with radiometric thermal imagery. Collect thermal LWIR, multiband VIS-NIR and high-resolution visual band image products in a streamlined, easy-to-use workflow.
Best-in-Class Multispectral Camera with Longwave Thermal Capabilities
The Sentera 6X family of sensors combines fast capture rates, outstanding optics, high-resolution, and exceptional spectral accuracy, and separation. Now you can add radiometrically accurate, pixel-level temperature measurement across entire images with precision data fidelity.
This best-in-class solution features a longwave infrared thermal camera, four simultaneously triggered, precision-filtered 3.2MP global-shutter imagers and one 20.1MP RGB imager, each with a dedicated, high-quality optical path.
What's included
- 1x 6X Thermal Sensor Pro with gimbal
- 1x ILS/GPS or GPS only module
- 1x Mounting brackets
Specifications
General
- Weight - 290 grams
- Dimensions - 7.95x6.6x6.76cm
- Power - 15W
- Imagery per trigger:
- (4) 12-bit TIF 3.2MP registered monochrome images
- (1) 16-bit TIF 320x256 radiometric thermal image
- (1) 8-bit JPG 20MP RGB image
- Sustained capture rate - 5fps
- Storage - 512GB internal PCIe NVMe
4X 3.2MP Monochrome Global Shutter
- HFOV - 47˚
- GSD @ 400ft - 2" (5.2cm)
- GSD @ 200ft - 1" (2.6cm)
- Spectral bands
- Green: 550nm x 20nm
- Red: 670nm x 30nm
- Red Edge: 715nm x 10nm
- NIR: 840nm x 20xm
1X 20MP RGB Electronic Rolling Shutter - Sony IMX147
- HFOV - 47˚
- GSD @ 400ft - 0.8" (2cm)
- GSD @ 200ft - 0.4" (1cm)
1X FLIR Boson 320x256 LWIR, Radiometric
- HFOV - 50˚
- Thermal accuracy - +/- 5˚C
- Thermal sensitivity - < 50mK
- GSD @ 400ft - 13.9" (35.5cm)
- GSD @ 200ft - 7" (17.7cm)
Light sensor
- Dimensions
- Weight - 55g
- Integrated GPS
Interfaces
- 1x USB-C (light sensor and GPS data)
- 1x Gigabit ethernet (data transfer and command/control)
- 1x 3.3V @1A output
- 1x 5V @1A output
- 2x 3.3V UART (U-blox, MAVLINK, DJI A3 metadata)
- 1x 3.3V pulse per second (PPS) for synchronisation
- 1x 3.3V shutter event output for synchronisation
- 1x 3.3V discrete trigger input
Features
- Real-time onboard multi-layer image registration
- 5 frames per second sustained capture rate
- Simple integration to drone platforms
- Optional ambient colour correction
- Optimal data products for manipulation and distribution
