DJI E-Port Development Kit

Product info

Convert the aircraft E-Port into multiple standard hardware ports. Convenient for connecting hardware equipment, SDK development, and debugging.

The development kit can convert the E-Port of the aircraft into multiple standard hardware ports like the XT30 Power Output Ports, USB 2.0 Port, and UART/PPS Signal Port, making it convenient for developers to connect hardware equipment and perform SDK development and debugging.

What's included

• 1x E-Port Adapter Board
• 1x Pin Header Protector
• 1x E-Port Coaxial Cable (150 mm)
• 1x XT30 to USB-C Power Cable (300 mm)
• 1x XT30 to DC5.5 Power Cable (300 mm)

Specifications

• Adapter Board Dimensions: 55×40×9 mm (L×W×H)
• XT30 VCC Power Output:
• DJI Mavic 3E/3T: 12-17.6 V/4 A
• Matrice 30 Series: 19.2-26.1 V/4 A
• Matrice 300 RTK: 24 V/4 A
• Matrice 350 RTK: 24 V/4 A
• XT30 12V Power Output: 12 V/2 A
• XT30 5V Power Output: 5 V/2 A
