Sentera - 6X Thermal Sensor

Sentera - 6X Thermal Sensor

A$25,850.00
In stock
Out of stock
-
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
+
Add to Cart
Need a hand with this product? Our are team are happy to help - get in touch.
SKU
00001

Product info

Sentera's best-in-class 6X multispectral sensor now with radiometric thermal imagery. Collect thermal LWIR, multiband VIS-NIR and high-resolution visual band image products in a streamlined, easy-to-use workflow.

Best-in-Class Multispectral Camera with Longwave Thermal Capabilities

The Sentera 6X family of sensors combines fast capture rates, outstanding optics, high-resolution, and exceptional spectral accuracy, and separation. Now you can add radiometrically accurate, pixel-level temperature measurement across entire images with precision data fidelity.

This best-in-class solution features a longwave infrared thermal camera, four simultaneously triggered, precision-filtered 3.2MP global-shutter imagers and one 20.1MP RGB imager, each with a dedicated, high-quality optical path.

What's included

  • 1x 6X thermal sensor with gimbal
  • 1x ILS/GPS or GPS only module
  • 1x Mounting brackets

Specifications

General

  • Weight - 290 grams
  • Dimensions - 7.95x6.6x6.76cm
  • Power - 15W
  • Imagery per trigger:
    • (4) 12-bit TIF 3.2MP registered monochrome images
    • (1) 16-bit TIF 320x256 radiometric thermal image
    • (1) 8-bit JPG 20MP RGB image
  • Sustained capture rate - 5fps
  • Storage - 512GB internal PCIe NVMe

4X 3.2MP Monochrome Global Shutter

  • HFOV - 47˚
  • GSD @ 400ft - 2" (5.2cm)
  • GSD @ 200ft - 1" (2.6cm)
  • Spectral bands
    • Green: 550nm x 20nm
    • Red: 670nm x 30nm
    • Red Edge: 715nm x 10nm
    • NIR: 840nm x 20xm

1X 20MP RGB Electronic Rolling Shutter - Sony IMX147

  • HFOV - 47˚
  • GSD @ 400ft - 0.8" (2cm)
  • GSD @ 200ft - 0.4" (1cm)

1X FLIR Boson 320x256 LWIR, Radiometric

  • HFOV - 50˚
  • Thermal accuracy - +/- 5˚C
  • Thermal sensitivity - < 50mK
  • GSD @ 400ft - 13.9" (35.5cm)
  • GSD @ 200ft - 7" (17.7cm)

Light sensor

  • Dimensions
  • Weight - 55g
  • Integrated GPS

Interfaces

  • 1x USB-C (light sensor and GPS data)
  • 1x Gigabit ethernet (data transfer and command/control)
  • 1x 3.3V @1A output
  • 1x 5V @1A output
  • 2x 3.3V UART (U-blox, MAVLINK, DJI A3 metadata)
  • 1x 3.3V pulse per second (PPS) for synchronisation
  • 1x 3.3V shutter event output for synchronisation
  • 1x 3.3V discrete trigger input

Features

  • Real-time onboard multi-layer image registration
  • 5 frames per second sustained capture rate
  • Simple integration to drone platforms
  • Optional ambient colour correction
  • Optimal data products for manipulation and distribution
